 PMEG4050EP_1 ? NXP B.V. 2009. All rights reserved. Product data sheet Rev. 01 — 14 September 2009 2 of 13 NXP Semiconductors PMEG4050EP 5 A low VF MEGA Schottky barrier recti?er 2. Pinning information [1] The marking bar indicates the cathode. 3. Ordering information 4. Marking 5. Limiting values Table 2. Pinning Pin Description Simpli?ed outline Graphic symbol 1 cathode [1] 2 anode 12 sym001 12 Table 3. Ordering information Type number Package Name Description Version PMEG4050EP - plastic surface-mounted package; 2 leads SOD128 Table 4. Marking codes Type number Marking code PMEG4050EP AF Table 5. Limiting values In accordance with the Absolute Maximum Rating System (IEC 60134). Symbol Parameter Conditions Min Max Unit VR reverse voltage Tj=25°C - 40 V IF(AV) average forward current square wave; δ = 0.5; f=20kHz Tamb ≤ 0 °C [1] -5A Tsp ≤ 130 °C-5A IFSM non-repetitive peak forward current square wave; tp =8ms [2] -70A Ptot total power dissipation Tamb ≤ 25 °C [3][4] - 625 mW [3][5] - 1050 mW [3][1] - 2100 mW |
